🧾 Overview
TrailFX provides LED light solutions to perform for work, play, and everyday life. Quality materials and workmanship go into each of our applications, including use of Cree and OSRAM LED's providing our lights with 30,000+ working hours. Buy once and with confidence knowing all TrailFX LED light solutions are covered by a Limited Lifetime Warranty.
- Higher Effective Lumens Fully Illuminates The Night Sky
- Die-Cast Aluminum Housing For Durability And Long Life
- A Combination 30 Degree Spot Beam And 60 Degree Flood Beam Allows Driver To See Further Down The Path, As Well As Everything Off The Trail Around You
- Auxiliary Lights Operate Independently To Increase Vehicle Visibility
- IP67 Rating For Dust, Sand, And Dirt Protection, Along With A High Water Resistance To Keep The Lights At 100 Percent Functional Capacity Regardless Of The Outside Elements
- 30,000+ Hours Of Working Life Assures The Light Will Operate For Work, Play, And Everyday Life
- Lower Power Consumption Allows Extra System Wattage For Additional Accessories
- Limited Lifetime Warranty
| Bulb Type | LED |
| Style | Straight |
| Length | 32 Inch |
| Beam Type | Combo Flood/ Spot Beam |
| Number Of Rows | Single |
| Light Color | Clear |
| Housing Color | Black |
| Smart Technology Compatible | Not Compatible With Smart Technology |
| Beam Angle (Deg) | 60 Degree Flood/ 30 Degree Spot |
| Lumens | 17280 Raw/ 12960 Effective Lumens |
| Wattage | 192 Watt |
| Width | 2.84 Inch |
| Height | 3.2 Inch |
| Voltage Rating | 12 Volt |
| Ampere Rating At 12 Volts | 12.8 Amp Draw Indicator Light / 20.48 Amp Draw High Beam |
| Ampere Rating At 24 Volts | 12.8 Amp Draw Indicator Light / 10.24 Amp Draw High Beam |
| Bulb Specifications | 24 Clear OSRAM 8 Watt LED Bulbs |
| Lens Material | Polycarbonate |
| Housing Material | Aluminum |
| Mounting Length | 34-1/2 Inch |
| Mounting Style | Side And Bottom Mount |
| Connection Type | Deutsch Connector |
| Includes | With Wiring Harness/ Side And Bottom Mounting Brackets/ Hardware |
| Estimated Install Time (Hours) | 1.5 |
