🧾 Overview
The ICON Vehicle Dynamics Stage 1 Suspension System for the 2021–2023 Ford Bronco equipped with the HOSS 1.0 suspension package is designed to increase wheel travel, improve damping control, and enhance ride quality on- and off-road. This system focuses on performance gains while retaining factory coil springs and OE mounting hardware for a clean, bolt-on upgrade.
Stage 1 includes ICON 2.5 EXP Series front and rear coilovers that provide adjustable ride height and improved heat dissipation over factory shocks. It is an ideal solution for drivers looking to upgrade shock performance without adding geometry-correcting components.
✔ Designed specifically for Broncos with HOSS 1.0 suspension
✔ Adjustable ride height using factory coils
✔ Improved damping and heat management over OE shocks
✔ Fully rebuildable and re-tunable shock design
✔ 100% bolt-on installation
🛠 Installation
- Direct bolt-on installation using factory mounting locations and OE coil springs. No cutting or welding required. Designed exclusively for Broncos equipped with the HOSS 1.0 suspension package. Professional installation and alignment are strongly recommended.
📌 Specs
- Key Features & Benefits
- Vehicle-specific tuned 2.5 EXP Series shocks for improved damping and control
- Adjustable ride height from 1.375–3" front and 1.5–2.25" rear using snap rings
- Utilizes factory coil springs and OE mounting hardware
- 2.5-inch aluminum shock bodies improve oil volume and heat dissipation
- 7/8-inch induction-hardened, chrome-plated shafts in shaft-up orientation
- Fully rebuildable and re-valvable shock design
- 100% bolt-on system with no cutting or welding required
📘 Specifications
- Brand: ICON Vehicle Dynamics
- System Type: Stage 1 Suspension System
- Front Lift Height: 1.375–3 inches adjustable
- Rear Lift Height: 1.5–2.25 inches adjustable
- Front Shocks: 2.5 EXP Series Coilovers (Internal Reservoir)
- Rear Shocks: 2.5 EXP Series Coilovers (Internal Reservoir)
- Shock Orientation: Shaft-up
- Installation Type: Bolt-on
- Tire & Wheel Fitment (Reference Only):
- OEM Wheels & Tires: Yes
- Recommended Aftermarket Wheels:
- 17x8.5" – 5.75" Backspace / 25mm Offset
- 18x9" – 6.00" Backspace / 25mm Offset
- Recommended Tire Size:
- 35" x 12.50" (high-clearance crash bars recommended, PN 42000)
- 37" tires require front bump stop spacers and trimming/modifications
📦 What’s Included (What’s in the Box)
- Front Components
- 2.5 EXP Series Front Coilover Shocks (HOSS 1.0)
- – Part Number: 48601
- – Quantity: 2
- Rear Components
- 2.5 EXP Series Rear Coilover Shocks (HOSS 1.0)
- – Part Number: 48611
- – Quantity: 2
🛡 Warranty
- Manufacturer-backed warranty provided by ICON Vehicle Dynamics. Shocks are fully rebuildable and serviceable.
⚠️ Fitment Notes
- Ford Bronco (HOSS 1.0 Suspension Package)
- 2021–2023 Ford Bronco
- HOSS 1.0 is standard on Base, Big Bend, Outer Banks, and Black Diamond trims without the Sasquatch package. OE HOSS 1.0 shocks are identified by black shock bodies.
⚠️ Fitment Notes
- Fits HOSS 1.0–equipped Broncos only. Not compatible with Bronco Raptor. Two-door models will sit taller than four-door models. Lift heights are based on stock-equipped vehicles. Lift heights above 2" over stock may require aftermarket front upper control arms to maintain proper alignment. Larger tire fitment may require high-clearance crash bars and additional bump stop spacing. Professional installation and alignment are recommended.
