🧾 Overview
The Factor 55 1.5" Hawse Fairlead (Gun Metal Gray) is a heavy-duty aluminum fairlead designed specifically for synthetic winch rope applications. Precision CNC-machined from 1.5-inch thick 6000-series aluminum bar, this fairlead exceeds the industry-standard 0.75-inch thickness to reduce rope stress and improve synthetic rope longevity—especially during high-angle or side pulls.
The increased thickness allows for a larger outer fillet radius, reducing abrasion and heat buildup on rope fibers. This fairlead also features a taller rope slot opening, making it compatible with larger 1/2-inch tube thimbles, a first in the industry. A machined outer chamfer further reduces rope stress during demanding winching scenarios, including suspension “suck-down” use.
Finished in a MIL-A-8625F Type III hard anodized gun metal gray coating, the fairlead offers superior abrasion resistance and low friction—key factors in extending the life of synthetic winch rope.
✔ Extra-thick 1.5" aluminum construction
✔ Designed exclusively for synthetic winch rope
✔ Reduces rope stress during angled pulls
✔ Hard anodized for maximum durability
🛠 Installation
- Installs on standard hawse fairlead mounting patterns
- Designed for use with synthetic winch rope only
- Mounting hardware not included
- Reuse winch-supplied bolts or select proper bolt length based on bumper thickness
- Professional installation recommended
📌 Specs
📌 Key Features & Benefits
- CNC-machined from 1.5" thick 6000-series aluminum
- Larger fillet radius reduces rope fiber stress
- Compatible with 1/2" synthetic rope tube thimbles
- Taller rope slot opening for increased clearance
- Machined outer chamfer reduces abrasion during side pulls
- MIL-A-8625F Type III hard anodized finish
- Low-friction surface reduces heat buildup
- Laser-engraved Factor 55 logo
- Manufactured in the USA
📐 Specifications
- Product Type: Hawse fairlead
- Thickness: 1.5 inches
- Overall Dimensions: 12.35" x 3.25"
- Material: 6000-series aluminum
- Finish: Type III hard anodized (Gun Metal Gray)
- Rope Compatibility: Synthetic rope only
- Thimble Compatibility: Up to 1/2" tube thimbles
- Mounting Hardware: Not included
📦 What’s Included
- 1.5" aluminum hawse fairlead
- Note: Mounting hardware not included.
🛡 Warranty
- Manufacturer-backed limited warranty
- Warranty coverage provided by Factor 55
⚠️ Fitment Notes
- Universal application
- Compatible with vehicles equipped with winches using synthetic rope
⚠️ Fitment Notes
- For synthetic winch rope only
- ❌ Not compatible with steel cable winch lines
- Mounting hardware not included
- Bolt length must be selected based on bumper and winch mounting thickness
- Recommended hardware: 3/8" Grade 5–8 bolts (1.25–1.5" shank) or 7/16" bolts
