🧾 Overview
The REDARC BCDC Trailer S is a compact power management solution designed to keep your trailer’s auxiliary battery charged while driving or off-grid. Combining a 12-amp DC-DC vehicle charger, a 40-amp MPPT solar regulator, and a smart battery isolator, this system simplifies trailer power management in one lightweight unit.
The BCDC Trailer S is specifically engineered to connect through a standard 7-way trailer plug and existing tow vehicle wiring, allowing for straightforward installation without running dedicated high-current charging cables. This makes it ideal for trailers where charging current is supplied through the vehicle’s towing harness.
Perfect for travel trailers, horse trailers, enclosed work trailers, mobile service units, and emergency response vehicles, the BCDC Trailer S ensures your trailer batteries stay charged while reducing reliance on shore power or generator charging.
✔ Combines DC-DC charging, solar regulation, and battery isolation
✔ Designed to work through a standard 7-pin trailer connection
✔ Ideal for off-grid and mobile trailer power systems
✔ Compact and lightweight for easy installation
🛠 Installation
- Designed to connect through a standard 7-way trailer plug and existing vehicle wiring, allowing the trailer battery to charge while towing. Solar panels can also be connected directly to the integrated MPPT solar regulator.
📌 Specs
- Integrated Power Management – Combines a DC-DC charger, MPPT solar regulator, and battery isolator into one compact unit.
- 12A Tow Vehicle Charging – Charges trailer batteries while driving using power supplied through the vehicle’s trailer wiring harness.
- 40A MPPT Solar Regulator – Maximizes solar charging efficiency for reliable off-grid power generation.
- Smart Battery Isolation – Prevents accidental discharge of the tow vehicle’s battery when the vehicle is not running.
- Tow Harness Compatible – Designed to safely draw charging current through existing trailer wiring without overloading circuits or fuses.
- Compact Lightweight Design – Easy to install inside trailers with minimal space requirements.
📘 Specifications
- Brand: REDARC
- Product Type: Vehicle-to-Trailer Battery Charger
- Tow Vehicle Charging Output: 12A
- Solar Regulator Capacity: 40A
- Charging Technology: DC-DC Charging + MPPT Solar Regulation
- Battery Protection: Integrated Smart Battery Isolator
- Installation: Trailer Electrical System
- Warranty: 2 Years
- Sold As: Single Unit
📦 What’s Included (What’s in the Box)
- Electrical Components
- (1) REDARC BCDC Trailer S Charger Unit
- Documentation
- Installation Instructions
🛡 Warranty
- Limited 2-Year Manufacturer Warranty provided by REDARC.
⚠️ Fitment Notes
- Suitable for trailers equipped with auxiliary battery systems, including:
- Travel trailers / camper trailers
- Horse trailers
- Enclosed cargo trailers
- Mobile service trailers
- Emergency response trailers
